Equinox Micro Bar Multi System Reloaded LED T Bar Par Cans Derby Laser Strobe Lighting Effects

Sold with a 12 Month Return to Base Warranty from EQUINOX
Free Shipping
Current Stock:
Adding to cart… The item has been added

A compact, all-in-one lighting package, the Equinox Microbar Multi System Reloaded includes a robust, heavy duty stand, heavy duty road bag, IR remote, 2 multi-colour LED Par panels and 3 light effects including derby, laser and strobe fitted to a powered T-bar. The 5 LED units are of a micro size and lightweight design. The user has control over colour, auto, sound active and DMX modes, via the LED display and push buttons. The IR remote gives instant and simple control over several control modes: blackout, auto, sound and colour.


  • Compact all-in-one lighting system with two pars, a derby, a laser, and a strobe bar
  • Also comes complete with a heavy-duty adjustable stand, heavy-duty road bag, and an IR remote
  • All of the fixtures boast a micro size and lightweight design, and attach to the included powered T-bar
  • Operate the system in colour, auto, sound active, DMX, and master/slave modes
  • Operation modes and adjustable parameters can be accessed through the T-bar's LED display and push buttons
  • The included IR remote provides instant and intuitive control over several control modes - blackout, auto, sound, and colour
  • Select between 3 or 12 DMX channels when utilising DMX control
  • 0 to 100-percent dimming, plus a variable strobe rate
  • Easy daisy-chaining thanks to 3-pin DMX I/Os and IEC power I/Os


  • Light Source:
    • Par Cans: 3 x 4W RGBW LEDs (each)
    • Derby: 4 x 3W LEDS (1 x Red, 1 x Green, 1 x Blue, 1 x White)
    • Laser: 1 x 100mW Red diode, 1 x 30mW Green diode
    • Strobe Bar: 6 x 4W White and UV LEDs
  • Par Can Beam Angle: 25°
  • Dimming: 0 to 100-percent
  • Strobe Rate: Variable
  • Operation Modes:
    • Auto
    • Sound Active
    • Master/Slave
    • DMX
    • Built-in programs
  • DMX Channels: 3 or 12, selectable
  • Display: LED display with 4-button menu
  • DMX Connectors: 3-pin IN and OUT
  • Power Connectors: IEC IN and OUT
  • Stand Height: Adjustable from 1600mm to 1850mm
  • Power Supply: 100-240V, 50/60Hz
  • Fuse: F3A 250V
  • Power Consumption: 70W
  • Dimensions: 200mm x 750mm x 165mm (without stand)
  • Weight: 6.3kg


  • 2 x RGBW LED Par Cans
  • 1 x RGBW Derby
  • 1 x Laser (Red and Green)
  • 1 x Strobe Bar (White and UV)
  • Microbar Height-Adjustable Stand
  • Carry Bag
  • Remote
