Sold with a 24 MONTH Return to Base Warranty from YAMAHA
An 18-in/18-out USB audio interface allows the MGX12 to function as a powerful front end for recording and streaming. Record individual channels directly into your DAW, use the secondary USB connection for simple two-channel device integration, and bring in wireless sources instantly using built-in Bluetooth audio.
DSP processing and dependable backup recording
Integrated DSP provides EQ, dynamics, and effects to help shape balanced, polished mixes with low latency. For added peace of mind, the MGX12 can record up to 16 tracks directly to a microSD card, making it ideal for live performances, mobile recording, and situations where secure backup capture is essential.
Features
- Fully digital mixing engine with touchscreen control interface
- 12-channel mixer for live sound, recording, and streaming
- 18-track USB audio interface for multi-track DAW recording
- Hands-on control via physical faders and channel controls
- Built-in DSP for EQ, dynamics, and effects processing
- Bluetooth audio input for wireless playback sources
- microSD recording for multi-track backup capture
- Compact design suitable for portable and installed systems
Specifications
- Mixing Channels:4 mono + 4 stereo + 1 sound pad + 2 FX return
- Fader Configuration:11 + 1 non-motorized faders
- Busses:8 MIX + 2 FX + 1 CUE + 1 STEREO
- Display:4.3-inch touchscreen with five control knobs
- Local Inputs:4 combo mic/line, 4 TRS line, 4 RCA line
- Local Outputs:2 XLR, 6 TRS, 4 headphone outputs
- USB Main:18-in/18-out audio interface, 32-bit, up to 96 kHz
- USB Sub:2-in/2-out audio interface, 16-bit, 48 kHz
- MicroSD Recording:Up to 16-track recording, 2-track playback
- Bluetooth:Bluetooth 5.0 audio input
- Dimensions (W x D x H):335 mm x 319 mm x 96 mm
- Weight:3.9 kg
- Included Accessories:Start guide, safety guide, Steinberg software license cards, Basic FX Suite license card, PA-300 power adapter
