Sold with a 7 YEAR Return to Base Warranty from YAMAHA
For smaller venues or temporary sound reinforcement setups that require serious power with a professional edge, look no further than this compact powerhouse.
The new DXS12mkII is equipped with an upgraded 1020W power amplifier producing an impressive 134dB and reaching as low as 42Hz producing clean, clear, heart-stopping bass that defies its lightweight construction.
Try selecting our D-XSUB “BOOST” or “XTENDED LF” low frequency processing settings, turn up the volume, and watch the eyes widen and jaws drop. All this in a small, easy to install enclosure.
Listeners will need to search for the source of this much low frequency performance.
Features
- Upgraded and improved high-output Class-D 1020W amplifier with precision damping
- Powerful 12'' low-frequency woofer with a 2.5'' voice coil
- Delivers 3dB higher sound pressure levels and 5Hz lower LF response compared to its predecessor
- Band-pass subwoofer with a rugged precision-engineered plywood enclosure
- Extended low frequency response from 42Hz to 150Hz
- D-XSUB DSP processing -
- NORMAL: Ideal linear frequency response
- BOOST: Tight and focused bass reproduction
- XTENDED LF: Enhanced low end
- Selectable cross-over - 80Hz, 100Hz, or 120Hz
- 2 x pole sockets - 1 x M20, and 1 x 35mm
- Cardioid bass-management system that reduces the SPL towards the stage, whilst increasing the SPL to the audience (for subwoofer arrays with a minimum of 2 subwoofers)
- Optional speaker covers and wheel kits available separately (not included)
Specifications
- Speaker Type: 12'' Powered/Active Subwoofer, Band-Pass Type
- Frequency Response: 42Hz - 150Hz
- Woofer: 12''
- Voice Coil: 2.5''
- Amplifier: Class-D
- Output Power: 1020W (Dynamic)
- Maximum Output Level: 134dB
- Processors: D-XSUB DSP - Boost Mode, Xtended LF Mode, Normal Mode
- Pole Socket:
- 1 x M20
- 1 x 35mm
- Enclosure: Plywood
- Weight: 30kg
