Yamaha DXR8 MKII 8" 1100W Active Powered PA Speaker

The Yamaha DXR8mkII 8'' Active PA Speaker is ideal for professionals who need powerful, clear sound in a compact form. This speaker boasts a robust 1100W power output, delivering an impressive maximum SPL of 130dB. Its advanced design includes a larger, lighter 1.75” Neodymium HF compression driver that ensures superior voice reproduction and musicality across performances.

The DXR8mkII’s durable ABS enclosure and intelligent onboard 3-channel mixer make it incredibly adaptable for both mobile performances and fixed installations. Its precise 48-bit DSP processing enhances sound quality, while extensive DSP protection functions maintain clarity at all output levels.

Maximum performance, minimal size

The Yamaha DXR8mkII is engineered to deliver exceptional power and clarity with its high-efficiency 1100W Class-D amplifiers, achieving an impressive 134dB SPL. This compact powerhouse provides fast attack and superior transient response, ensuring that every note is delivered with precision and impact. Ideal for venues where space is at a premium but high output is necessary, this speaker performs without compromise.

Clear sound through advanced acoustics

This speaker features a 1.75” Neodymium HF compression driver that offers enhanced clarity and musicality, particularly in voice reproduction. Combined with the innovative wide dispersion constant directivity horn, the DXR8mkII projects sound smoothly across a broad coverage area, minimizing sound deterioration in oblique directions and ensuring consistent audio quality throughout the listening space.

Versatility for every event

The DXR8mkII is housed in a rugged, non-resonant ABS enclosure that withstands the demands of touring while dampening vibrations for less distortion at high volumes. Its onboard mixer is capable of handling three simultaneous inputs, accommodating a range of sources from microphones to instruments. The flexible HPF control and smart mixing/linking functions provide further customization, making it easy to tailor the sound to any event.

Built for easy placement and portability

Ease of setup is a hallmark of the DXR8mkII, with dual-angle pole mount sockets allowing for optimal sound direction, avoiding reflective surfaces and ensuring the audience experiences the best possible sound. Additionally, its compact design is complemented by ergonomic, gripped aluminium handles and a robust steel grille, enhancing both portability and durability. Whether mounted, placed on a stand, or rigged with optional brackets, this speaker adapts seamlessly to the specific needs of each performance environment.

Features

• Astounding 130 dB SPL output from only 12.8 kg of weight
• Register your product with Yamaha and receive an extended 7-year warranty
• D-contour intelligent multi-band compressor optimises your sound
• FIR-X tuning crossover stops phase issues in the mid-range
• Two 35 mm speaker pole mounts at 0° and 7°
• Super-efficient class D amplification with 700 watts continuous output
• Integrated 3 channel mixer lets you easily balance input sources
• Easy to use presets for different rooms and PA configurations

Specifications

General

• System type: 2 way, bi-amped, bass reflex powered speaker
• Frequency range (-10 dB): 57 Hz - 20 kHz
• Coverage angle: H 90° x V 60° constant directivity horn
• Crossover type: FIR-X tuning (linear phase FIR filter)
• Max SPL (peak): 130 dB SPL

Transducers

• Low frequency:
  • Diameter: 8'' cone
  • Voice coil: 2''
  • Magnet: Ferrite
• High frequency:
  • Voice coil: 1.75''
  • Diaphragm: PET
  • Type: 1'' throat compression driver
  • Magnet: Neodymium

Enclosure

• Material, finish, colour: ABS, matte black
• Dimensions (WxHxD): 280 x 458 x 280 mm
• Net weight: 12.8 kg
• Pole socket: 35 mm x 2 (0° or 7°)
• Rigging points: Top x 2, Rear x 1, fits for M8 eyebolts

Amplifier

• Amplifier type: Class-D
• Dynamic power rating: 1100 watts
• Continuous power rating: 700 watts
• Cooling: fan cooling, 4 speeds
• AD/DA: 24 bit, 48 kHz
• Signal processing: 48 bit
• HPF/LPF: off, 100, 120 Hz 24 dB/octave
• DSP presets: D-contour, FOH/main, monitor, off
• Input connectors: 1 x XLR/1/4'' jack combo, 2 x 1/4'' jack, 2 x RCA pins
• Output connectors: 2 x XLR
• Idle power consumption: 35 watts
