Studiomaster Core 121 Line Array with 12" Sub PA System with Built In Mixer and Bluetooth

The Studiomaster CORE 121 is a versatile and self-contained portable PA system, combining a powerful 12” subwoofer with a curved array featuring three 5” midrange drivers and nine 1” tweeters. Designed for clear, dynamic sound and wide coverage, it includes an integrated 4-channel DSP mixer with Bluetooth connectivity, making it an ideal choice for musicians, DJs, presenters, and small venues.

High-Powered Performance with Integrated Subwoofer

The CORE 121 delivers an impressive 700W to the 12” bass reflex subwoofer and 300W to the mid/high array, producing deep, punchy bass and crystal-clear highs. Its phase-inverted design ensures maximum efficiency and impact, making it well-suited for live performances and events where powerful, full-range sound is required.

Curved Array for Exceptional Coverage

The unique curved array design enhances audience coverage, providing a 100° horizontal and 70° vertical dispersion pattern. With three neodymium 5” midrange drivers and nine 1” dome tweeters, this system offers even sound distribution across a wide area, outperforming traditional compact PA setups.

Cable-Free Design and Easy Setup

A specially designed pneumatic speaker pole seamlessly connects the subwoofer and array, transmitting both audio and power without external cables. The robust wooden cabinet features an angled control panel for easy access mid-performance, along with a durable paint finish and ergonomic handles for effortless transportation.

Built-In 4-Channel DSP Mixer with Bluetooth

The integrated mixer offers two mic/line inputs, a Hi-Z instrument input, and a stereo line/Bluetooth input, eliminating the need for an external mixing desk. A simple DSP interface with an LCD screen provides quick access to EQ settings, output delay, and mix controls, with selectable DJ, Music, and Vocal presets for tailored sound adjustments.

Features

• 12” active subwoofer with 700W power output for deep bass
• Curved array with three 5” midrange drivers and nine 1” tweeters for wide dispersion
• Integrated 4-channel DSP mixer with mic, instrument, and Bluetooth inputs
• Cable-free connection between the subwoofer and array via a pneumatic speaker pole
• Angled control panel for easy setup and adjustment during performances
• Compact and portable design with a durable wooden cabinet and ergonomic handles
• Selectable DSP presets (DJ, Music, Vocal) with EQ, limiter, and delay controls

Specifications

Sub Bass

• Speaker:  1×12” low frequency driver
• Rated power (SUB):  700W (rms)
• Amplifier power:  700W (LF) + 300W (MF/HF) (rms)
• Max SPL:  128dB
• Dimensions:  405mm x 590mm x 470mm
• Net weight :  27kg

Curve Array

• Speaker MF:  3×5” Neodymium full range driver
• Speaker HF:  9×1” dome tweeter
• Rated power:  300W
• Coverage:  100° (h) x 70° (v)
• Dimensions:  185mm x 495mm x 220mm (315mm max)
• Net weight:  8kg

Control

• DSP:  24bit module with mode, EQ, limiter, delay and mix level control
• Inputs:  2x mic (XLR) / line (6.35mm jack) balanced, 1x instrument Hi-Z (6.35mm jack), 1x stereo line (RCA phono) / Bluetooth®
• Outputs:  2x balanced line / link output (XLR), 1x balanced line / link MIX output (XLR)
