Shure SLXD24UK/B58-K59 Wireless Vocal System with Beta 58 Handheld Microphone

The Shure SLXD24UK/B58-K59 is a wireless microphone system that delivers a flawless wireless experience worthy of prestigious events and professional touring. Vivid, high-resolution digital audio meets unmatched signal stability bringing you the clearest sound possible with more balance and clarity than you've heard before.

Setup is brilliantly easy. At the push of a button SLX-D handles frequency management for you without complication, all at lightning speed. Because the SLX-D is built to go big, you can grow your system with total confidence. Whether it's one channel or ten, SLX-D guarantees wireless excellence wherever required.

Authentic Beta 58 sound - set free

The SLXD2 transmitter combines the classic Beta 58 capsule with forward thinking wireless technology. For the sound you know and trust, securely transmitted over a 100 meter range.

One-press IR sync establishes a rock solid connection from transmitter to receiver in a matter of seconds. Whilst a mini LCD screen and intuitive controls let you see what's important. Navigate between group/channel, frequency, or battery runtime with ease. You can also engage 'lock mode' to prevent unwanted button presses mid-performance.

And because the mic capsule is interchangeable, you can customise the transmitter to suit the performer. Shure's selection of famous sound signatures give you all the flexibility you need.

Powerful rechargeability options

SLX-D transmitters give you 8 hours of use from one pair of AA batteries. But why not take advantage of Shure's revolutionary rechargeable technology?

The optional SB903 lithium-ion battery provides a hefty 10 hours of run time. And you can see exactly how much life is left directly from your transmitter.

There are a variety of charging options too: the SBC10-903 Single-Battery USB charger. Or the SBC203 Dual Docking Station - which allows battery charging in or out of their transmitters thanks to external charging contacts. It only takes 2.5 hours to reach full power. Or in emergencies, a 15-minute quick charge provides a vital hour of use.

Built for hard touring

A faulty wireless system can have show stopping consequences. Which is why SLX-D receivers are virtually bullet-proof. Made from enforced galvanized steel and put through extreme testing procedures, SLX-D is ready for the long haul. And then some.

And with the included rackmount kit you can install you're entire wireless rig into a hardcase. For convenient and safe transportation from venue to venue.

Features

SLXD2/B58 Wireless Handheld Microphone Transmitter

• Clear, uninterrupted signal over 100 meter range
• Up to 8 hours of continuous use with 2 AA batteries
• IR sync pairs transmitter with receiver at the push of a button
• Exceptionally detailed 24-Bit / 48kHz digital audio with over 120 dB of dynamic range
• Selectable LCD display shows group/channel, frequency, or battery runtime
• Interchangeable Beta 58 capsule for the iconic sound you know and trust
• Integrated shock mount and pop filter for clear and clean sound
• Cardioid polar pattern rejects unwanted background noise
• Lock mode avoids any accidental changes

SLXD4 Digital Wireless Receiver

• Run up to 32 systems in a 44mHz band; 10 systems per 6MHz TV band; 12 systems per 8 MHz band
• Manage multiple system group scans, firmware updates and control via Ethernet
• Automatic Channel Scan quickly finds clear frequencies
• Digital Predictive Switching completely eliminates drop-outs
• Full bandwidth 20Hz-20kHz frequency response
• High resolution LCD menu and intuitive controls
• Lock mode avoids any accidental changes
• Half rack format with detachable BNC 1/4 wave antennas
• Tour proof galvanized steel housing
• XLR and 6.3mm instrument output

Specifications

SLXD4 Receiver

• Weight: 1.8 lb (816 g), without antennas
• Dimensions (H x W x D): 42 × 197 × 152 mm
• Power Requirements: Supplied by included power supply
• RF Input:
• Spurious Rejection: > 75 dB, typical
• Connector Type: BNC
• Impedance: 50 Ω
• Audio Output:
• Gain Adjustment Range: –18 to +42 dB in 1 dB steps
• Configuration: 1/4" (6.35 mm) and XLR: Balanced
• Impedance: 50 Ω
• Full Scale Output: 1/4": +12 dBV, XLR: LINE setting = +15 dBV, MIC setting = −15dBV
• Mic/Line Switch: 30 dB pad
• Phantom Power Protection: Yes
• Networking:
• Network Interface: Single Port Ethernet 10/100 Mbps
• Network Addressing Capability: DHCP or Manual IP address
• Maximum Cable Length: 100 m (328 ft)

SLXD2/B58

• Capsule Type: Dynamic
• Polar Pattern: Supercardioid
• Battery Type: Shure SB903 Rechargeable Li-Ion or AA batteries 1.5 V
• Battery Runtime: Shure SB903: up to 10 hours, AA: up to 8 hours
• Dimensions Diameter x Length): 1.46 × 6.93 in (37.1 × 176 mm)
• Weight: 5.2 oz. (147 g), without batteries
• Audio Input:
• Configuration: Unbalanced
• Maximum Input Level: 8.2 dBV
• RF Output:
• Antenna Type: Integrated Single Band Helical
• Occupied Bandwidth: 200kHz
• Modulation Type: Shure proprietary digital
• Power: 1 mW or 10 mW
