Shure SLXD14/SM35-K59 Wireless Headset Microphone System

The Shure SLXD14UK/SM35-K59 is a wireless microphone system engineered to provide a seamless and reliable wireless experience, meeting the demands of professional touring environments. It offers high-resolution digital audio complemented by exceptional signal stability, ensuring optimal clarity and balanced sound reproduction.

The system features straightforward setup; frequency management is automated at the touch of a button, streamlining the process for efficient deployment. Designed for scalability, the SLX-D allows users to expand their system with assurance, accommodating configurations from a single channel to multiple channels while maintaining consistent wireless performance in any setting.

Authentic Shure sound - set free

The SM35 headset microphone has been integrated with forward thinking wireless technology. For pristine Shure quality audio, securely transmitted over a 100-meter range.

One-press IR sync establishes a rock-solid connection from your bodypack transmitter to receiver in a matter of seconds. Whilst a mini-LCD screen and intuitive controls let you see what's important. Navigate between group/channel, frequency, or battery runtime with ease. You can also engage 'lock mode' to prevent unwanted button presses mid-performance.

Powerful rechargeability options

SLX-D transmitters give you 8 hours of use from one pair of AA batteries. But why not take advantage of Shure's revolutionary rechargeable technology?

The optional SB903 lithium-ion battery provides a hefty 10 hours of run time. And you can see exactly how much life is left directly from your transmitter.

There are a variety of charging options too: the SBC10-903 Single-Battery USB charger. Or the SBC203 Dual Docking Station - which allows battery charging in or out of their transmitters thanks to external charging contacts. It only takes 2.5 hours to reach full power. Or in emergencies, a 15-minute quick-charge provides a vital hour of use.

Built for hard touring

A faulty wireless system can have show stopping consequences. Which is why SLX-D receivers are virtually bullet-proof. Made from enforced galvanized steel and put through extreme testing procedures, SLX-D is ready for the long haul. And then some.

And with the included rackmount kit you can install your entire wireless rig into a hardcase. For convenient and safe transportation from venue to venue.

Features

SM35 Headset Microphone

• Comfortable wire frame design
• Flexible gooseneck for quick, easy adjustments
• Secure fit even during energetic performances
• Clear, detailed sound similar to quality handheld mics
• Cardioid polar pattern focuses only on your voice
• Windscreens tame plosives for improved intelligibility
• Reliable in extremely hot and humid environments
• Clothing clip keeps cable tucked away
• Permanently charged condenser capsule (phantom power not required)

SLXD1 Bodypack Transmitter

• Clear, uninterrupted signal over 100-meter range
• Up to 8 hours of continuous use with 2 AA batteries
• IR sync pairs transmitter with receiver at the push of a button
• Exceptionally detailed 24-Bit / 48kHz digital audio with over 120 dB of dynamic range
• Backlit LCD screen with easy to navigate menu and controls
• Selectable display shows group/channel, frequency, or battery runtime
• Lock mode avoids any accidental changes
• 4-Pin male mini connector (TA4M)
• Detachable 1/4 wave antenna

SLXD4 Digital Wireless Receiver

• Run up to 32 systems in a 44mHz band; 10 systems per 6MHz TV band; 12 systems per 8 MHz band
• Manage multiple system group scans, firmware updates and control via Ethernet
• Automatic Channel Scan quickly finds clear frequencies
• Digital Predictive Switching eliminates drop-outs
• Full bandwidth 20Hz-20kHz frequency response
• High resolution LCD menu and intuitive controls
• Lock mode avoids any accidental changes
• Half rack format with detachable BNC 1/4 wave antennas
• Tour proof galvanized steel housing
• XLR and 6.3mm instrument output

Specifications

SM35 Headset Microphone

• Connector: TA4F (TGQ)
• Transducer Type: Condenser
• Frequency Response: 40Hz - 20kHz
• Polar Pattern: Cardioid
• Phantom Power Requirement: Supplied from bodypack
• Output Impedance (@ 1 kHz): 2400 Ω
• Audio Output Level: -59.0 dBV/Pa
• Signal-to-noise Ratio (@ 1 kHz): 55 dB
• Maximum SPL (1000 Ω load, 1 kHz @ 1 THD): 153.0 dB
• Dynamic Range (@ 1 kHz, 1000 Ω load): 114.0 dB
• Equivalent Output Noise (typical, A-Weighted): 39 dB
• Cable: 1.1 m
• Weight: 0.072 kg

SLXD1 Bodypack Transmitter

• Battery Type: Shure SB903 Rechargeable Li-Ion or AA batteries 1.5 V
• Battery Runtime: Shure SB903: up to 10 hours, AA: up to 8 hours
• Dimensions (H x W x D): 3.86 × 2.68 × 1.0 in (98 × 68 × 25.5 mm)
• Weight: 3.1 oz (89 g) without batteries
• Housing: PC/ABS
• Audio Input:
  • Connection: 4-pin male mini connector (TA4M)
  • Configuration: Unbalanced
  • Impedance: 1 MΩ
  • Maximum Input Level: 8.2 dBV (7.27 Vpp)
  • Preamplifier Equivalent Input Noise (EIN): −118 dBV, A-weighted, typical
• RF Output:
  • Connector: SMA
  • Antenna Type: 1/4 wave
  • Impedance: 50 Ω
  • Occupied Bandwidth: 200kHz
  • Modulation Type: Shure proprietary digital
  • Power: 1 mW or 10 mW

SLXD4 Receiver

• Weight: 1.8 lb (816 g), without antennas
• Dimensions (H x W x D): 42 × 197 × 152 mm
• Power Requirements: Supplied by included power supply
• RF Input:
  • Spurious Rejection: > 75 dB, typical
  • Connector Type: BNC
  • Impedance: 50 Ω
• Audio Output:
  • Gain Adjustment Range: –18 to +42 dB in 1 dB steps
  • Configuration: 1/4" (6.35 mm) and XLR: Balanced
  • Impedance: 50 Ω
  • Full Scale Output: 1/4": +12 dBV, XLR: LINE setting = +15 dBV, MIC setting = −15dBV
  • Mic/Line Switch: 30 dB pad
  • Phantom Power Protection: Yes
• Networking:
  • Network Interface: Single Port Ethernet 10/100 Mbps
  • Network Addressing Capability: DHCP or Manual IP address
  • Maximum Cable Length: 100 m (328 ft)
