Shure GLXD+ Dual Band Wireless Guitar Pedal System with WA305 Premium Guitar Cable, GLXD1+ Digital Bodypack, and GLXD6+ Guitar Pedal Receiver

The Shure GLXD14+ Digital Wireless Guitar System is a wireless instrument system that's perfect for guitars and live sound in a range of contexts. Well-suited to small-to-medium-sized music venues, houses of worship, and conference halls, this system offers a full and complete guitar sound with the convenience of a wireless setup. Operating with brand-new dual-band wireless technology, the GLX-D+ will scan for the cleanest possible channels within its 2.4 GHz band as well as its 5.8 GHz band, for stable and interference-free performances always.

The GLX-D+ system also provides automatic pairing between transmitters and receivers, making it incredibly convenient for travelling performers, or events with rapid turnarounds - simply plug in and perform! A redesigned rechargeable lithium-ion battery offers up to 12 hours of continuous use from a single charge, and a quick charge feature that gives 1.5 hours of use from a 15-minute charge. Included in this system is the WA305 wireless instrument cable, letting you plug straight from guitar to bodypack, reducing the need for long, trailing cables without compromising on sound quality.

All-new dual-band technology

A new development for this revised system, the GLX-D+ family operates in both 2.4 GHz and 5.8 GHz wireless frequency ranges. Both digital and license-free in most countries worldwide (please refer to the included map for exceptions), this new design more than doubles the available bandwidth this system has to find a clean, clear channel for the best sound quality and stability feasible. This system will automatically scan to find a suitable channel when turned on, without you needing to press a button. Not only that, but the system will select backup frequencies to jump to if interference does unexpectedly appear, keeping your show running smoothly, clearly and without dropouts.

Extended battery life

Shure has taken lengths to redesign the GLX-D+ lithium-ion battery pack to extend its use. Now offering up to 12 hours of continuous use at the 5.8 GHz band, and 17 hours in the 2.4 GHz band, this system can last throughout long events.

Built for guitars

The included WA305 instrument cable offers guitarists freedom of movement whilst clearing the stage of any long, trailing wires typically needed for running guitars live. Using the clip-on bodypack transmitter and cable, it's simple to use and ensures your guitar sounds full and excellent.

Features

• Dual-band digital wireless system provides exceptional RF performance
• Operates in both 2.4 GHz and 5.8 GHz wireless frequency ranges for broader bandwidth
• Ease of finding clean channels to prevent interference and dropouts
• Automatically selects backup frequencies to switch to in case of sudden interference
• Instantly pairs transmitters and receivers for quick and easy setup
• New and improved rechargeable lithium-ion battery delivers up to 12 hours of battery life
• Quick-charge function gives you 1.5 hours of battery from a 15 minute charge
• Includes bodypack transmitter and WA305 instrument cable for transmitting guitars
• Compact, convenient pedal format with tuning mode

Specifications

GLXD6 Dual Band Guitar Pedal Receiver

• Dimensions (H x W x D): 5.4 x 3.7 x 1.89 in. (138 x 95 x 48 mm)
• Weight: 19.75 oz. (560 g)
• Housing: Aluminium alloy
• Power Requirements: 9 V - 15 V, 400mA (efficiency level VI power supply)
• Spurious Rejection: >35 dB, typical
• Gain Adjustment Range: -20 to 40 dB in 1 dB steps
• Configuration: 6.35 mm (1/4“) output Impedance balanced
• Impedance: 6.35 mm (1/4“) output 100Ω (50Ω, Unbalanced)
• Maximum Audio Output Level: 6.35 mm (1/4“) connector (into 3 kΩ load) +8.5 dBV
• Pin Assignments: 6.35 mm (1/4“) connector Tip=audio, Ring/Sleeve=ground
• Audio Input Modes: Tuner or True Bypass
• Impedance: 50Ω
• Antenna Type: Dual Band Internal Monopole
• Maximum Input Level: −20 dBm

GLXD1+ Dual Band Bodypack Transmitter

• Dimensions (H x W x D): 4.5 x 2.6 x 1.1 in (115 x 66.94 x 28.51 mm), without antenna
• Weight: 5.4 oz. (153.1 g), without battery
• Power Requirements: 3.7 V rechargeable, lithium ion
• Housing: Cast metal, black powdercoat
• Input Impedance: 900 kΩ
• RF Output Power: 10 mW E.I.R.P. max.
• Input Connector: 4-pin male mini connector (TA4M)
• Input Configuration: Unbalanced
• Maximum Input Level (1 kHz at 1% THD): +8.4 dBV (7.5 Vp-p)
• Antenna Type: Dual Band Internal Monopole
• Pin Assignments TA4M:
• 1: Ground (cable shield)
• 2: +5 V bias
• 3: Audio
• 4: Tied through active load to ground (On instrument adapter cable, pin 4 floats)

Shure WA305 Instrument Cable

• Product Code: WA305
• Connectors: TA4F / TQG (4-pin) to 6.3 mm angled jack mono
• Length: 78 cm
