Electro-Voice Evolve 50 Portable 1000W Active Column Speaker Black

The Electro-Voice Evolve 50 is the perfect combination of lightweight portability and superior audio quality.

Featuring eight 3.5'' neodymium drivers, a 12'' low-frequency woofer and a class-D amplifier, the Evolve 50 delivers a maximum SPL of 127dB and a frequency response of 37Hz to 20kHz.

The new Electro-Voice Evolve 50 features an intuitive and powerful QuickSmartDSP section which allows you to optimise the acoustic performance to suit any medium-sized venue.

Consisting of an aluminium pole, a column array and a subwoofer, the Evolve 50 can be quickly setup and easily transported from venue to venue.

Portable and Powerful

The perfect choice for DJs, mobile entertainers, bands, singer/songwriters and any venue where high-output portable sound is needed – no other column system currently available sounds as good, looks as good or is as easy to use as the Electro-Voice Evolve 50 offering the smooth clarity of EV sound in a sleek new form factor.

Innovative DSP

Controllable via a single-knob interface with an LCD display, the QuickSmart DSP consists of four pre-sets - Music, Live, Speech and Club - along with a three-band EQ, five user-programmable pre-sets, system-match crossovers, metering and master volume control. The Electro-Voice Evolve 50 is equipped with the QuickSmartDSP which provides best-in-class processing and versatility for instantly optimising the sonic performance to suit any environment.

Wireless Control

The QuickSmartMobile app allows you to control up to six Electro-Voice Evolve 50 array systems simultaneously. Simply connect to each speaker via Bluetooth® to optimise the sound from anywhere in the venue and receive immediate notification during critical performance conditions.

Features

• Clean, compact design – built to blend in
• Angled interface provides easy access to make adjustments and connections on the input panel
• Legendary EV audio quality via eight 3.5'' full-range drivers and a 12'' subwoofer, powered by a three-channel amp for high output
• Cutting-edge components and tuning provide full-sized sound in a super-streamlined, plug-and-play format
• Custom waveguides provide ultra-wide 120° horizontal coverage and array-formed 40° asymmetrical vertical pattern
• Exceptional audience coverage and clarity from front to back
• High-quality Bluetooth® audio for convenient wireless audio streaming
• Wireless control and monitoring via the new Bluetooth® QuickSmartMobile app
• Quickly configure up to six Evolve 50 systems simultaneously, and receive immediate notification during critical performance conditions
• QuickSmartDSP provides best-in-class processing via EV’s signature single-knob user interface and LCD display
• Four pre-sets (Music, Live, Speech, Club), three-band EQ, five user pre-sets, output delay, phantom power, input level control and metering, and master volume control
• Lightweight column speaker array with cable-free connection quickly secures pole to sub
• Convenient transport and quick setup
• Ergonomically designed handles on both the array and the sub to enhance portability

Specifications

• Frequency Response: 37Hz - 20kHz, -10dB
• Maximum SPL: 127dB
• High-Frequency Drivers: 3.5'' Neodymium Drivers
• Low-Frequency Driver: 12'' Woofer
• Power Handling: 1000W
• High-Frequency: 500W
• Low-Frequency: 500W
• Amplifier Type: Class-D
• Crossover Frequency: 200Hz
• Coverage: 120° x 40° (H x V)
• Input Connectors:
• 2 x XLR/TRS Combo Jacks
• 1 x 3.5mm Jack
• 1 x Stereo RCA
• Wireless Bluetooth®
• Output Connectors:
• 1 x XLR Thru
• 1 x XLR Mix Out
• Grille: Steel with White Powder Coat
• Enclosure Material: Wood
• Dimensions:
• Sub: 471mm x 345mm / 18.5'' x 13.6'' (D x W)
• Column: 172mm x 102mm / 6.9'' x 4'' (D x W)
• Pole: 55mm x 48.5mm / 2.2'' x 1.9'' (D x W)
• Power Supply: 100V - 240V AC, 50Hz - 60Hz
• Weight: 26.25kg
