Alto Professional TS410 Active 10" PA Speaker

What Are The Features Of The TS410?

Three-Channel Mixer

The Alto TS410 features an integrated three-channel mixer. The mixer has a Mic/Line input on channels 1 and 2, and a dedicated Bluetooth connection on channel 3. The Mic/Line channels are combo jack inputs, which accept both XLR and TRS. Channels 1 and two also have a Mic/Line switch, to adjust the gain structure depnding on the input source. If connecting to a mixing desk, set to LINE. If connecting a microphone directly to the speaker, set to MIC.

Bluetooth Compatibility

Bluetooth connectivity makes it easy to pair your phone, tablet or laptop to the TS4 and begin streaming audio in no time. On top of that, Alto has introduced True Wireless Stereo, which lets you stream audio to one speaker, and then wirelessly pair that speaker to another TS4 series speaker.

DSP Presets

On the Alto TS410, the DSP allows you to alter the sound depending on its use. The three Speaker Use modes on the TS410 are Live, DJ and Custom. There is also a fourth option, EQ Off, which sets the speaker to its default flat response.

NEW and FREE Alto Professional App

We live in a digital world these days. Therefore, Alto has taken another leap forward into that world. Developed for Android and IOS, the Alto Professional app acts as a wireless remote for the TrueSonic TS4 Series speakers. Naturally called 'Alto Pro' on the app store, the app allows you to set Bluetooth Levels, Speaker Use Modes, Custom EQ and Sub-Size Crossover. Moreover, you can remotely configure True Wireless Stereo to save you time during setup.

Variable Crossover Filters

The TS410 has 3 selecteable crossover postions for use with a subwoofer. "SMALL" which is for 12" subwoofers, "MEDIUM" which is for 15" inch subwoofers and "LARGE" which is for 18" inch subwoofers.

What Does The 'Speaker Use' Mode Do?

The speaker use button will adjust your speaker to control the output EQ based on what is streaming through your speaker.

• EQ Off - Sets a flat response, best for general use.
• Live - Adds a bump in the upper midrange frequencies and a cut in the low-end frequencies.
• DJ - Boosts the high-end and low-end for added clarity and thump.
• Custom Via App - Control the EQ using the free Alto Pro app.

How Do I Adjust The EQ Settings On The Alto TS410?

For more control, the Alto Pro app offers a 6-band parametric EQ. So, you can now make remote adjustments to the EQ from any listening point in the venue.

In the Alto Pro app, navigate the EQ section to manipulate the EQ response. After that, load the EQ to your TS4 Series speaker by pressing Load To Speaker. In addition, you can save your favourite custom EQ settings for later use.

What Does The Sub Size Button Do?

If you intend on pairing a TS4 speaker with a subwoofer, the Sub Size button optimizes the low frequencies. In other words, it allows the TS4 speakers to work efficiently. Here are the technical values of the Sub Size settings:

• Large (18-inch Subwoofer) - Roll off at 80Hz
• Medium (15-inch Subwoofer) - Roll off at 95Hz
• Small (12-inch Subwoofer) - Roll off at 110Hz

If not using a subwoofer, the Full Range, No Sub setting produces a full low-end output of your TS4 speaker.

Frequently Asked Questions

How Do I Pair My Alto Professional TS4 Series Speaker With A Bluetooth Device?

To connect a TS410 speaker to a Bluetooth device, follow these steps:

• Hold down the pairing button for three seconds to initiate pairing mode.
• The blue LED on the speaker will flash, indicating that it is in pairing mode.
• Navigate to your Bluetooth device and select Alto TS410.
• When the connection is successful, there will be a voice prompt, and the blue LED will be lit solid.

How Do I Stereo Link Two TS4 Series Speakers Wirelessly?

To set up the stereo link mode, do the following steps:

• Connect one speaker to a Bluetooth device by following the steps above. After that, this will be the primary speaker.
• Hold the LINK pairing button for 3 seconds to initiate the stereo link. Do this for both speakers.
• Both speakers will beep to indicate they are in scanning mode, and the orange LED will blink. When they find each other, they will link automatically.
• Once the two speakers are successfully linked, there will be a confirmation chime, and the Orange LED will be lit solid.
• Press and hold the pair button on either speaker to disconnect. Once the speakers are in the stereo link, the Bluetooth Volume knob on either speaker will control the volume for both speakers. Mix Out does not include Bluetooth signal, only analogue inputs.

Bear in mind that the average maximum range for Bluetooth is 10 metres, considering the environment is unobsrtucted.

Are there covers for the Alto Professional TrueSonic TS4 Series?

Yes, there are covers exclusively for the TS4 models. So, click here to check Music Gear Direct website if you're after Alto TS4 covers.

How much does the Alto TS410 weigh?

The Alto TS410 weighs roughly 11.8kg

Do I have to use the Alto Pro app?

No. The Alto Pro app is optional. Therefore, you can control the TS4 Series speakers using the mixer and DSP on the back. However, the app is the only way to access the Custom EQ feature.

How powerful is the Alto TS410?

According to Alto, the TS410 delivers 2000 watts peak output.

What is the power output of the USB charging output on the Alto TS410?

The USB Charge output size is 5v, 2.1A. This output is used for charging devices, and cannot be used to stream media from storage or media devices.
