Features
- 800 W continuous program power capacity
- 76 mm (3 in) copper voice coil
- 40 - 3000 Hz response
- 5 dB sensitivity
- Ventilated voice coil gap for reduced power compression
Specifications
- Nominal diameter 380 mm (15.0 in)
- Nominal impedance 8 Ω
- Minimum impedance 6.3 Ω
- Nominal power handling 400 W
- Continuous power handling 800 W
- Sensitivity (1W/1m) 98.5 dB
- Frequency range 40 - 3000 Hz
- Voice coil diameter 76 mm (3.0 in)
- Winding material Copper
- Former material Glass Fibre
- Winding depth 19 mm (0.75 in)
- Magnetic gap depth 11 mm (0.43 in)
- Flux density 1.15 T
Design
- Surround shape Triple Roll
- Cone shape Exponential
- Magnet material Neodymium Inside Slug
- Spider Single
- Pole design Straight Pole
- Woofer cone treatment WP Waterproof Front Side
- Recommended enclosure 100.0 dm3 (3.53 ft3)
- Recommended tuning 47 Hz
